Breakout Fiber Cable Price from China
The robust construction of Uni-fiber's Breakout Fiber Cables make them ideal for demanding environments, including conduits, junction boxes, patch panels and the factory floor. They offer all the ease of a 900 µm tight buffered termination with only one fiber per sub-unit. To support rugged applications, the connector and cable's aramid yarns are bonded together to provide unmatched strength and durability.
Breakout Fiber Features & Benefits
-
1.Easy, Consistent Field Terminations: 900 µm tight buffered fibers make termination simpler
-
2.Facilitates rugged bond between connector & fiber with its 2mm & 3mm single fiber sub-units offering
-
3.Robust Construction: Ideal for demanding environments
-
4.Unmatched Strength: Aramid yarns bonded together to provide durability
Breakout Fiber Cable
This cable is offered in a riser and plenum rated constructions and is ready to accept industry standard connectors. Available in all glass sizes including the new 10 gigabit transmitting fibers.
Breakout Cable Applications:
- 1.Office Cabling
- 2.Computer room
- 3.Indoor/Outdoor Breakout
Plenum/Riser Breakout Fiber Optic Cable Specifications
| DESCRIPTION |
UNITS |
4 ELEMENT |
6 ELEMENT |
8 ELEMENT |
12 ELEMENT |
24 ELEMENT |
| Crush (Short Term) |
N/100 mm |
1000 |
1000 |
1000 |
1000 |
1000 |
| Strength member |
|
FRP/Aramid |
FRP/Aramid |
FRP/Aramid |
FRP/Aramid |
FRP/Aramid |
| Storage Temperature |
°C |
-20~+60 |
-20~+60 |
-20~+60 |
-20~+60 |
-20~+60 |
| Installation Temperature |
°C |
0~+50 |
0~+50 |
0~+50 |
0~+50 |
0~+50 |
| Operating Temperature |
°C |
-20~+60 |
-20~+60 |
-20~+60 |
-20~+60 |
-20~+60 |
| Nominal Weight |
kg/km |
46 |
63 |
86 |
139 |
159 |
| Fiber count |
n |
4 |
6 |
8 |
12 |
24 |
| Nominal Outer Diameter |
mm |
7.0 |
8.2 |
9.4 |
11.8 |
14.1 |
| Maximum Tensile Load (installation) |
N |
500 |
1000 |
1100 |
1400 |
1400 |
| Maximum Tensile Load (installed) |
N |
270 |
600 |
700 |
700 |
700 |
| Minimum Bend Radius (installation) |
mm |
140 |
160 |
190 |
240 |
280 |
| Minimum Bend Radius (installed) |
mm |
70 |
80 |
95 |
120 |
140 |
| Fire Performance |
CPR EuroClass |
Eca |
Eca |
Eca |
Eca |
Eca |
| Drum Length |
km |
2 |
2 |
2 |
2 |
2 |
