GYFXBY Flat-shape & Self-supporting Uni-tube Fiber Optic Cable
IntroductionOptical fibres are housed in a loose tube that is made of high-modulus plastic and filled with tube filling compound. Two glass fibre reinforced plastic(FRP)rods are placed outside the tube in parallel, and water-blockingyarns is placed between the tube and the rods, then a flat-shape PE sheath is extruded.
In the distribution segment of optical networks in rural areas, the cable can be used as drop cables for self-supporting aerial installation to connect branching points with access points for subscribers.
Features
Accurate process control ensuring good mechanical and temperature performances
Unique flat shape providing excellent crush resistance,applicable to special wedge clamps for installation
Two FRP strength members in parallel close to the tube, easy for stripping
All-dielectric design, applicable to lightning-prone areas
Uni-tube,small ize and light weight, easy for installation
Product Series
| 1 | Feeder segment | GYTA/GYTS | Stranded Loose Tube |
| 2 | Distribution segment | GYAXZY | Uni-tube Aramid LSZH Sheath |
| GYGXZY | Uni-tube Glass Yarn PE Sheath | ||
| GTJGA | Slotted TBF APL CSM | ||
| GYFXBY | Flat-shape & Self-supporting Uni-tube | ||
| GYAXTC8Y | Figure-8 Self-supporting Uni-tube Aramid | ||
| GYFC8A-3U | 3-Unit FRP APL Figure-8 Self-supporting | ||
| 3 | Drop segment | GJXH | Bow-type drop cable |
Parameters
| Type | Diameter mm |
Weight (kg/km) |
Diameter FRP | Tensile strength Long/short term (N) |
Crush Long/short term (N/100mm) |
| GYFXBY-02-24Xn | 4.6*8.1(3.0tube) | 35 | 1.6 | 400/1400 | 1000/5000 |
