Lesotho OPGW-24B1-127 Optical Ground Wire Price from Manufacturer in China
OPGW Cable Features
- 1.Preferred option for easy handling and splicing
- 2.Thick-walled aluminum pipe provides excellent crush resistance
- 3.Hermetically sealed pipe protects optical fibers
- 4.Outer wire strands selected to optimize mechanical and electrical properties
- 5.Optical sub-unit provides exceptional mechanical and thermal protection for fibers
- 6.Dielectric color-coded optical sub-units available in fiber counts of 6, 8, 12, 18 and 24
- 7.Multiple sub-units combine to achieve fiber counts up to 144
Optical Ground Wire Applications
- 1.For use by electric utilities on transmission lines in lieu of traditional shield wire
- 2.For retrofit applications where existing shield wire needs to be replaced with OPGW
- 3.For new transmission lines in lieu of traditional shield wire
- 4.Voice, video, data transmission
- 5.SCADA networks
OPGW-24B1-127 [59.2;151.3]
OPGW Cable Specifications |
Quantity |
10KM |
| Date |
20210726 |
Structure |
|
Material |
No |
Material |
No. |
Material Dia. |
| Fiber |
G.652 |
24 |
|
|
|
| Center |
30%AS wire |
1 |
|
|
Diameter |
3.00 |
mm |
| Layer1 |
30%AS wire |
5 |
|
|
Diameter |
3.00 |
mm |
| |
SUS Tube |
1 |
Fibers(all tube) |
24 |
Tube-Dia. |
3.00 |
mm |
| Layer2 |
AA wire |
12 |
|
|
Diameter |
3.00 |
mm |
| |
|
|
|
|
|
|
|
| |
|
|
|
|
|
|
|
| |
Technical Data |
according to IEC, IEEE standards |
| stranding direction of outer layer is right hand(Z-stranding) |
| Cable Diameter |
15.00 mm |
| Cable Weight |
496.0 kg/km |
| Supporting Cross Section |
127.23 mm2 |
| Section of AS Wire 42.41 mm2 |
| Section of AA Wire 84.82 mm2 |
| Ultimate Tensile Strength (UTS) |
64.90 kN |
| Rate Tensile Strength (RTS) |
59.23 kN |
| Modulus of Elasticity (E-Modulus) |
87.3 kN/mm2 |
| Thermal Elongation Coefficient |
18.4 × 10-6/℃ |
| Permissible Maximum Working Stress (40% RTS) 186.2 N/mm2 |
| Everyday Stress (EDS) ( 18%~25% RTS) 83.8 ~116.4 N/mm2 |
| Ultimate Exceptional Stress (70% RTS) 325.9 N/mm2 |
| DC Resistance |
0.311 Ω/km |
| Short Time Current ( 1s, 20℃~200℃) 12.30 kA |
| Short Time Current Capacity I2t |
151.29 kA2S |
| Minimum Bending RadInstallation： |
300 mm |
| Oprating： |
225 mm |
| Temperature Range: |
Installation |
- 10℃ ~ +50 ℃ |
| Transportation and Operation -40℃ ~ +80 ℃ |
How to Order Cable OPGW
Our team is committed to providing outstanding service before, during, and after the sale. To learn more about our products or to place an order, please contact your sales representative. WhatsApp/Mobile/WeChat our Customer Service Department at
+86 186 3866 8721 or email us at
info@uni-fibercable.com
