NF M 87-202 EGSF

APPLICATION AND DESCRIPTION

These NF M 87-202 EGSF instrumentation cables are used for safety extra-low use in petroleum and petrochemical units particularly for the transmission of a.c. or d.c. analogue signals.

CABLE CONSTRUCTION

Conductor	Solid or Stranded copper conductor
Insulation	PVC (70 mm maximum pair length)
Binder tape	Polyster tape
Collective Screen	Aluminium/polyester tape
Outer Sheath	PVC (Flame retardant, sunlight, mineral oil and hydrocarbon resistant)
Outer Sheath Colour	Light-blue

Core identification

Colours	Natural	Red	Blue	Yellow
1 pair	√	√
1 triple	√	√	√
1 quad	√	√	√	√

Natural cores printed with pair/triple number

STANDARDS REFERENCES

NF M 87-202
UTE C 32-014
NF C 32-020
IEC 60332-1
IEC 60332-3-24

CHARACTERISTICS

Voltage Rationg	300/500V
Operating Temperature	-40°C/+90°C
Installation Temperature	MAX+50°C
Maximum Voltage	250V
Voltage Test	2000V

Maximum conductor d.c. Resistance

Conductor Size	Ohm/km at +20°C
1/0.80mm(0.50 sqmm)	37.50
7/0.40mm(0.88 sqmm)	21.40
7/0.53mm(1.50 sqmm)	12.50

Capacitance between cond. (nf/km)

0.5 sqmm ≤ 145
0.88 sqmm ≤ 160
1.50 sqmm ≤ 180

Type/codification

1 Serie	Number of pairs, triples or quads / 01 to 27
2 Serie	Lay up in pair(IP) ,triple (IT) , quads (IQ)
3 Serie	Core section 05 (0.5mm²) , 09 (0.88 mm²) or 15(1.5mm²)
4 Serie	Overall screen(EG) or individual screen + overall screen(EI)
5 Serie	Mechanical protection: without armour (SF), with armour (FA), with lead + armour(PF)

CABLE PARAMETER

NF M 87-202	Number of beams x cross section	Cond. mm²	Outer Diameter(mm)		Weight (kg/km)
			Min.	Max
03 IP 05 EGSF	3X2X0.5	0.50	8.00	9.30	95
07 IP 05 EGSF	7X2X0.5	0.50	10.50	12.10	160
12 IP 05 EGSF	12X2X0.5	0.50	13.40	15.40	255
19 IP 05 EGSF	19X2X0.5	0.50	16.60	19.00	380
27 IP 05 EGSF	27X2X0.5	0.50	19.20	22.00	510
01 IQ 09 EGSF	1X4X0.88	0.88	7.00	8.20	90
01 IP 09 EGSF	1X2X0.88	0.88	6.10	7.20	65
03 IP 09 EGSF	3X2X0.88	0.88	10.50	12.00	150
07 IP 09 EGSF	7X2X0.88	0.88	14.00	16.00	280
12 IP 09 EGSF	12X2X0.88	0.88	17.90	20.40	440
19 IP 09 EGSF	19X2X0.88	0.88	22.00	25.30	665
27 IP 09 EGSF	27X2X0.88	0.88	25.80	29.60	880
01 IP 15 EGSF	1X2X1.50	1.50	6.80	7.80	83
07 IT 05 EGSF	7X3X0.50	0.50	12.00	13.80	210
12 IT 05 EGSF	12X3X0.50	0.50	15.50	17.10	375
01 IT 09 EGSF	1X3X0.88	0.88	6.40	7.50	80
07 IT 09 EGSF	7X3X0.88	0.88	16.40	18.10	410
12 IT 09 EGSF	12X3X0.88	0.88	20.80	22.90	660
01 IT 15 EGSF	1X3X1.50	1.50	7.20	8.20	100
