AS/NZS 3599.2 HV XLPE Insulated ABC Cable 6.35/11kV & 12.7/22kV

AS/NZS 3599.2 HV XLPE Insulated ABC Cable 6.35/11kV & 12.7/22kV

High Voltage Aerial Bundled Cables -XLPE Insulated Metallic screened 11kV 22kV; XLPE Insulated Non Metallic Screened 11kV 22kV

AS/NZS 3599.2 HV ABC Cable Description

11kV 22kV 3C XLPE insulated non metallic screened aerial bundled cables with aluminium alloy support conductor to AS/NZS 3599.2 Also available with HDPE Sheath
11kV 22kV 3C XLPE insulated cu.wire screened aerial bundled cables with with galvanised steel catenary to AS/NZS 3599.2

11kV 22kV XLPE Non Metallic Screened Aerial Cable Physical Data

XLPE insulated non-m etallic screened aerial bundled cables to AS/NZS 3599.2 Aluminium conductors, aluminium alloy 1120 support conductor.
Nominal conductor area
mm2
Nominal conductor diameter mm Average insulation thickness mm Nominal diameter over insulation mm Average insulation screen thickness mm Nominal diameter over core mm AAAC/1 1 20 support conductor Nominal overall diameter mm Approx mass kg/km
Size no/mm Diameter mm
6.35/11kV
35 6.9 3.4 14.9 1 17.1 7/4.75 14.3 48.4 1170
50 8.1 3.4 16 1 18.2 7/4.75 14.3 50.7 1320
70 9.6 3.4 17.6 1 19.8 7/4.75 14.3 53.9 1560
95 11.4 3.4 19.3 1 21.5 7/4.75 14.3 57.3 1860
120 12.8 3.4 20.7 1 22.9 19/3.50 17.5 63.3 2280
150 14.2 3.4 22.1 1 24.3 19/3.50 17.5 66.2 2570
185 15.7 3.4 23.6 1 25.8 19/3.50 17.5 69.2 2890
12.7/22kV
35 6.9 5.5 19.2 1 21.4 7/4.75 14.3 57.1 1540
50 8.1 5.5 20.3 1 22.5 7/4.75 14.3 59.3 1710
70 9.6 5.5 21.9 1 24.1 7/4.75 14.3 62.5 1990
95 11.4 5.5 23.6 1 25.8 7/4.75 14.3 66 2310
120 12.8 5.5 25 1 27.2 19/3.50 17.5 72 2760
150 14.2 5.5 26.4 1.1 28.8 19/3.50 17.5 75.2 3100
185 15.7 5.5 27.9 1.1 30.3 19/3.50 17.5 78.2 3460
AAAC/1120 Support Conductors
Stranding & nom. wire dia no/mm  Nominal overall diameter mm Cross-sectional area
mm2
DC resistance at 20°C at 20°C Minimum breaking load
kN
Recommended tension Modulus ofelasticity Gpa Coeff. of linear expansion 10 –6/°C
Highest everyday kN Max. working
kN
7/4.75 14.3 124 0.239 27.1 4.1 13.6 59 23
19/3.50 17.5 182.8 0.163 41.7 6.3 20.9 56 23


11kV 22kV XLPE Metallic Screened Aerial Cable

XLPE Insulated Metallic Screened 11kV
Part No. Nominal conductor area
mm2
Nominal
conductor
diameter
mm
Average insulation screen thickness mm Copper wire screen stranding
no/mm
Nominal diameter over screen mm Average sheath thickness
mm
Nominal diameter over sheath mm Galvanised steel catenary stranding
no/mm
Nominal
overall
diameter
mm
Approx.
mass
kg/km
AERMV3X35SCN11kV 35 6.9 0.8 24/0.85 19.2 1.8 23.5 19/2/00 57.1 2060
AERMV3X50SCN11kV 50 8.1 0.8 24/0.85 20.4 1.8 24.7 19/2/00 59.3 2230
AERMV3X70SCN11kV 70 9.6 0.8 24/0.85 22.0 1.8 26.3 19/2/00 62.5 2500
AERMV3X95SCN11kV 95 11.4 0.8 24/0.85 23.7 1.8 28.0 19/2/00 66.0 2820
AERMV3X120SCN11kV 120 12.8 0.8 24/0.85 25.1 1.8 29.4 19/2/00 68.8 3100
AERMV3X150SCN11kV 150 14.2 0.8 24/0.85 26.5 1.9 31.0 19/2/00 72.0 3440
AERMV3X185SCN11kV 185 15.7 0.8 24/0.85 28.0 1.9 32.5 19/2/00 75.0 3800

XLPE Insulated Metallic Screened 22kV
Part No. Nominal conductor area
mm2
Nominal
conductor
diameter
mm
Copper wire screen stranding
no/mm
Nominal diameter over screen mm Average sheath thickness
mm
Nominal diameter over sheath mm Galvanised steel catenary stranding size
no/mm
Galvanised steel catenary stranding diameter
mm
Nominal overall diameter
mm
Approx. mass
kg/km
AERMV3X35SCN22kV 35 6.9 24/0.85 23.5 1.8 27.8 19/2/00 10.0 65.7 2500
AERMV3X50SCN22kV 50 8.1 24/0.85 24.7 1.8 29.0 19/2/00 10.0 68.0 2690
AERMV3X70SCN22kV 70 9.6 24/0.85 26.3 1.9 30.8 19/2/00 10.0 71.6 3020
AERMV3X95SCN22kV 95 11.4 24/0.85 28.0 1.9 32.5 19/2/00 10.0 75.0 3370
AERMV3X120SCN22kV 120 12.8 24/0.85 29.4 2.0 34.1 19/2/00 10.0 78.2 3720
AERMV3X150SCN22kV 150 14.2 24/0.85 30.8 2.0 35.5 19/2/00 10.0 81.0 4060
AERMV3X185SCN22kV 185 15.7 24/0.85 32.3 2.1 37.2 19/2/00 10.0 84.4 4470
