(Mini ADSS) ASU 80 120 Self-Supporting Drop Cable G.652D
The typical ASU (Mini ADSS) Self-supporting Drop Optical cable includes Central Tubes with optical fibre(s),Two Glass FRP as the strength members, a LSZH Sheath is extruded outside.
Features
- Lighting resistance
- Non-metallic structure
- Duct installation and aerial installation together with tension strandwire
- Suitable for FTTH application as drop cable
| Type | Diameter mm |
Weight (kg/km) |
Tensile strength Long/short term (N) |
Crush Long/short term (N/100mm) |
Bending Radius Static/Dynamic |
| ASU-80 | 6.8(2.0tube) | 45 | 300/600 | 300/600 | 10D/20D |
| ASU-120 | 7.8(2.5tube) | 60 | 300/600 | 300/600 | 10D/20D |
